CALIFORNIA ENERGY COMMISSION

The CFM levels for this model have been tested and certified by the laboratories of the California Energy Commission. More info.

SPECIFICATIONS

MODEL SIZE COLOR CFM SONES SPEED LIGHT DUCT AMP / GAUGE RECIRCULATING
RA-35U30SS 30″ Stainless Steel 700 9.0 3 LED x 2 8″ vertical 4 / 19 No
RA-35U36SS 36″ Stainless Steel 700 9.0 3 LED x 2 8″ vertical 4 / 19 No
RA-35U42SS 42″ Stainless Steel 700 9.0 3 LED x 2 8″ vertical 4 / 19 No
RA-35U48SS 48″ Stainless Steel 800 9.0 3 LED x 3 8″ vertical 4 / 19 No

Download manual

FEATURES

  • 3 speed electronic push button control with LCD indicator and delay shut-off.
  • Dual 250 watt infrared heat lamp option. (Heat lamp not included)
  • Duel high performance squirrel cage motor.
  • Wall-mount available. (Duct cover sold seperately)

ACCESSORIES & OPTIONS

MODEL DESCRIPTION SIZE COLOR NOTE
RA-35BF Baffle filter Stainless Steel 1 piece
RA-3530DC Duct cover 30″ x 12″ x 12″ Stainless Steel 1 piece
RA-3536DC Duct cover 36″ x 12″ x 12″ Stainless Steel 1 piece
RA-3542DC Duct cover 42″ x 12″ x 12″ Stainless Steel 1 piece
RA-3548DC Duct cover 48″ x 12″ x 12″ Stainless Steel 1 piece
BS30 Backsplash 30″ x 30″ Stainless Steel 1 piece
BS36 Backsplash 36″ x 30″ Stainless Steel 1 piece
BS42 Backsplash 42″ x 30″ Stainless Steel 1 piece
8″ DAMPER Damper 8″ 1 piece
PC16 Medium-duty power cord
16 gauge / 3 wire / 13 amp / 120 volt / 1,500 watt capacity
44-1/2″ 1 piece

DIAGRAM

RA-35 diagram
